IoT Tutorial #16 [ Raspberry Pi Tutorials #4 & NodeMCU Tutorials #4 ]

In Previous post, we have seen how we can initialize CGI server on Raspberry Pi 3 and use it as a Gateway for  Node-Gateway IoT Architecture.

Here, I will demonstrate, how we can send live temperature data to ThinkSpeak server using Node-Gateway IoT architecture and observe the real-time Temperature vs Time graph on https://thinkspeak.com

NodeMCU (ESP8266) will be used as Node and RPi3 will be used as Gateway.


In this program,
Analog Temperature sensor (LM35) is connected to the NodeMCU 1.0 (ESP-12E Module) (ESP8266MOD) board and Its output will be sent to Gateway (Raspberry Pi 3).
  1. A C-Program (NodeMCU_to_RPi3_Temp-APDaga.ino) is written and uploaded on NodeMCU ESP8266, which will collect real-time room temperature using LM35 Sensor. and will then send that temperature data to RPi3 (Gateway).
  2. In order to send the data to RPi3 (Gateway), Above mentioned C-Program will trigger a python script "ts.py" kept in /cgi-bin/ folder on RPi3 using CGI Server
  3. This "ts.py" script, will log the received temperature data into a text file "TS_Out.txt" and then send the same data to thinkspeak server where we can see the graph between temperature vs time.

1. Internal 10 bit ADC (A0) is used to read the Analog output of the Temperature Sensor.
2. Temperature data shown on thinkspeak server grapth will be subset of Logged temperature data in text file on RPi3.
    (Because free version of thinkspeak server accept data with the gap of 16 sec interval)

Steps to configure Arduino IDE to connect to NodeMCU ESP8266 are given Here.

Physical Connections:

NodeMCU Board  ->  LM35 (Analog Tempt Sensor)
3V3 -> Vcc (Left Pin - Flat side facing towards you)
A0 -> Analog Out (Middle Pin) (10mV / degree Celcious)
GND -> Gnd (Right Pin - Flat side facing towards you)

PIN Diagram of ESP8266MOD NodeMCU 1.0 (ESP-12E Module) Board:
| o . o . o . o . o . o . o . o . o . o . o . o . o . o . o |
| Facing ur side |
| |
| 3V3 GND Tx Rx D8 D7 D6 D5 GND 3V3 D4 D3 D2 D1 D0 |
| o . o . o . o . o . o . o . o . o . o . o . o . o . o . o |

Serial Communication with PC through MicroUSB cable (Tx0 and Rx0)

Steps for Execution:

1. Sign up at https://thingspeak.com
2. Channels > New Channel > Update "Name" and "Field 1" field names > Save Channel
3. Click On API keys > Copy "Write API key"
4. Make all the Connections to Arduino Mega board mentioned Above.
5. Check ip address of RPi3 using "ifconfig" command
6. Change Following 3 fields in C-program: (NodeMCU_to_RPi3_Temp-APDaga.ino) to be uploaded on NodeMCU.
a. ip of RPi3 (from step 5)
b. ssid_name (Name of you WiFi)
c. password (Password of your WiFi)
d. path of file name of python script running on RPi3 // Here it is: ts.py

7. Change the following field in the below python program: (ts.py)
a. api_key (from step 3)
and save this python program as "ts.py"

8. Place this python program "ts.py" to ~/cgi-bin/ folder.
and make it executable: chmod +x ~/cgi-bin/Blink_LED_Server.py

9. Start CGI server on RPi3:
Open Terminal on RPi3:
a. cd ~
b. cp /usr/lib/python2.7/CGIHTTPServer.py ~/
c. python -m CGIHTTPServer

you will see the response on the terminal as follows:
Serving HTTP on port 8000 ...

10.Upload Program to NodeMCU 1.0 (ESP-12E Module)

11.Open Arduino Serial Monitor on PC (Set Baud Rate to 115200 and set "Both NL & CR")

12.Go to https://thingspeak.com and login
Channels > My Channels > Click on Channel Name (created in step 2) > Private View
Here you can observe the Grapth of Temperature Vs Day.
13.Check logged data on RPi3:
Open terminal in RPi3:
a. cd ~
b. vi TS_Out.txt

For Better understanding you can watch demonstration video given below:


Download link is given in the Description of the YouTube video shown below.


NodeMCU_to_RPi3_Temp-APDaga.ino: (To be uploaded on NodeMCU)

* ip of RPi3
* ssid
* password
* path for ts.py python script (if needed)

#include <ESP8266WiFi.h>

const char* host = ""; // ip of RPi3
//String ApiKey = "FHLRDWDK7GXTF83S"; // Not needed
String path = "/cgi-bin/ts.py?field1="; // ts.py is the name of python script running on RPi3

const char* ssid = "SuiteUp"; // ssid_name
const char* pass = "welcome@10"; // password

int sensor = A0; // LM35 Analog Output

float tempc;
float svoltage;

void setup(void){ // Function to Connect to Wi-Fi

WiFi.begin(ssid, pass);

// Wait for connection
while (WiFi.status() != WL_CONNECTED) {

Serial.print("Connected to ");
Serial.print("IP address: ");

void loop() {
float xval = analogRead(sensor); // Read Analog output from LM35 Temperature Sensor
svoltage = (xval*3100.0)/1023; // value in mili volt
tempc = svoltage/10; // value in degree celcius

Serial.println(tempc); // display on serial monitor

WiFiClient client;

const int httpPort = 8000;
if (!client.connect(host, httpPort)) { // connect to RPi3 CGI server with port no. 8000
Serial.println("connection failed");

// send temperature data to RPi3 CGI server
client.print(String("GET ") + path + String(tempc) + " HTTP/1.1\r\n" +
"Host: " + host + "\r\n" +
"Connection: keep-alive\r\n\r\n");

// Format of the string for temp=25.4 is:
// GET /cgi-bin/ts.py?field1=25.4 HTTP/1.1\r\nHost:\r\nConnection: keep-alive\r\n\r\n

delay(10000); // wait for 1 sec

(To be kept in /cgi-bin/ on RPi3)

#!/usr/bin/env python

# api_key (from step 3)

# importing libraries
import cgi
import httplib, urllib
import time

sleep = 20

api_key = '7O4GGQFQGGPLYGF5' # Thinkspeak API_key

def thermometer(val): # Function to send data to thinkspeak server using API
temp = val
params = urllib.urlencode({'field1': temp, 'key':api_key }) # set parameter for post/update request of thinkspeak server
headers = {"Content-type": "application/x-www-form-urlencoded","Accept": "text/plain"} # set header for post/update request of thinkspeak server

conn = httplib.HTTPConnection("api.thingspeak.com:80") # connect to thinkspeak server

conn.request("POST", "/update", params, headers) # Send post / update request to Thinkspeak server
response = conn.getresponse() # read response from thinkspeak server
print temp # print temperature
print response.status, response.reason # print response from thinkspeak server
data = response.read()
conn.close() # close connection

print "connection failed" # print error

if __name__ == "__main__": # main function start here
# while True:
form = cgi.FieldStorage() # received form from Arduino

val = form.getvalue('field1') # Temp data from Arduino

f=open("TS_Out.txt",'a') # Open file in append mode
f.write(str(val)+' \n') # write temperature data in the file
f.flush() # copy from buffer to file
f.close() # Close file

thermometer(val) # Function to send data to thinkspeak server using API

# time.sleep(sleep) # wait for desired amount of time

Click here to see more codes for Raspberry Pi 3 and similar Family.
Click here to see more codes for NodeMCU ESP8266 and similar Family.
Click here to see more codes for Arduino Mega (ATMega 2560) and similar Family.

Feel free to ask doubts in the comment section. I will try my best to solve it.
If you find this helpful by any mean like, comment and share the post.
This is the simplest way to encourage me to keep doing such work.

Thanks and Regards,
-Akshay P. Daga


  1. Is this wifi communication between R-pi and ESP based on MQTT protocol?

    1. This is HTTP communication. But you can find MQTT protocol in next blogs. Use Top-Right search bar.
